JXG-213-W

Product Overview

The JXG-213-W offers all the features of the JXG-213-F but utilizes the wrist to scan and provide an accurate body temperature measurement. The only difference is the temperature detection module measures the wrist temperature instead of the forehead temperature. This model provides rapid and accurate body temperature detection. With a shorter distance between the wrist and the temperature sensor, the accuracy significantly increases. The JXG-213-W offers temperature detection and facial recognition as an option at the same time, audio/visual alarm for those who have an elevated temperature, and API integration into an existing security system. This system has a wide range of applicable uses, which include schools, office buildings, hospitals, and any other area that needs to increase safety by scanning for abnormal body temperatures.

Applicable Uses

  • Railways stations
  • Government Buildings
  • Bus stations
  • Enterprises and Institutions
  • Airports
  • Shopping malls
  • Hospitals
  • Parks
  • Schools
  • Any other public places
Specification Table
Features Parameter Description
Operation System Linux
Face Recognition Accuracy Rate >99%
Face Recognition Time 200ms
Face Capacity 10,000
Card Capacity 100,000
Storage Capacity 4GB
Event Capacity 8,000 (with images)
Measurement Range 86℉ - 113℉
Measurement Accuracy 0.18℉
Measurement Deviation ≤0.54℉
Measurement Distance 1cm-4cm
Authentication Mode Face Whitelist: (1:N)
Card:(1:N)
Face +Body temperature
Mask Detection
Door Opening Method Face, Password, QR code, Card
Communication Mode 10/100Mbps adaptive network port
Card Type Mifare 1 Card
User Management Support user library addition, deletion, update
Record Management Support local recording and real-time upload
Interface LAN×1, Wiegand Input×1, Wiegand Output×1, RS485×1, Alarm Input×2, Alarm Output×1, USB2.0×1, Lock×1, Door Contact ×1, Exit Button×1
Power Supply Input 12V±25% DC
Weight 7.7KG
Screen Touch Screen, Size:7 inch, Resolution: 600×1024
Camera Dual Lens, 2MP, 1080P
Supplement Light LED soft light and infrared light
Dimensions (L×W×H) For terminal : 134.0mm×33.0mm×305.0mm
Working Environment For terminal: -4℉-149℉, Relative Humidly<95% (non-condensing)
For module: 50℉-104℉
Protection Level Both terminal and module: IP 54
Application Situation Indoor, No wind
